AMD RYZEN 7 7700X3D 8-Core, 16-Thread Desktop Processor [Box]

Technical Specifications
Name: AMD Ryzen™ 7 7700X3D
Family: Ryzen
Series: Ryzen 7000 Series
Form Factor: Desktops , Boxed Processor
Market Segment: Enthusiast Desktop
Regional Availability: Global
Former Codename: Raphael AM5
Processor Architecture: Zen 4
# of CPU Cores: 8
Multithreading (SMT): Yes
# of Threads: 16
Max. Boost Clock: Up to 4.5 GHz
Base Clock: 4 GHz
L1 Cache: 512 KB
L2 Cache: 8 MB
L3 Cache: 96 MB
Default TDP: 120W
Processor Technology for CPU Cores: TSMC 5nm FinFET
Processor Technology for I/O Die: TSMC 6nm FinFET
CPU Compute Die (CCD) Size: 71mm²
I/O Die (IOD) Size: 122mm²
Package Die Count: 2
AMD EXPO™ Memory Overclocking Technology: Yes
Precision Boost Overdrive: Yes
Curve Optimizer Voltage Offsets: Yes
AMD Ryzen™ Master Support: Yes
CPU Socket: AM5
Supporting Chipsets: A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
CPU Boost Technology: Precision Boost 2
Instruction Set: x86-64
Supported Extensions: AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE2 , SSE4.2 , SSE4A , SSE4.1 , SSE3 , SSSE3 , SSE , x86-64
Thermal Solution (PIB): Not Included
Recommended Cooler: Liquid cooler recommended for optimal performance
Max. Operating Temperature (Tjmax): 89°C
Launch Date: 07/16/2026
*OS Support: Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Native USB 3.2 Gen 2 (10Gbps): 4
Native USB 3.2 Gen 1 (5Gbps): 0
Native USB 2.0 (480Mbps): 1
PCI Express® Version: PCIe® 5.0
Native PCIe® Lanes (Total/Usable): 28 , 24
NVMe Support: Boot , RAID0 , RAID1 , RAID10
System Memory Type: DDR5
Memory Channels: 2
Max. Memory: 128 GB
System Memory Subtype: UDIMM
Max Memory Speed: 2x1RDDR5-52002x2RDDR5-52004x1RDDR5-36004x2RDDR5-3600
ECC Support: Yes (Requires mobo support)
Graphics Model: AMD Radeon™ Graphics
Graphics Core Count: 2
Graphics Frequency: 2200 MHz
USB Type-C® DisplayPort™ Alternate Mode: Yes
