Specifications
General Specifications
Operating Ambient Temperature: 0–40 °C
Dimensions: 120 (L) x 120 (W) 27 (H) mm
Net Weight: 172 g
Fan Specifications
Fan Speed: 500 -3000 rpm PWM Controlled
0 rpm below 5% PWM
Airflow: 73 cfm | 124 m³/h
Static Pressure: 4.5 mmH2O
Fan Bearing: Fluid Dynamic Bearing
Typical Voltage: 12 V DC
Start Up Voltage: 3.5 V DC
Current: 0.4 A
Cable Length: 400 mm + 80 mm Daisy-Chain Cable
Connector: 4-Pin Fan Plug + 4-Pin Socket
RGB Specifications
LEDs: 12x A-RGB Gen2 LEDs
Current | Voltage: 0.40 A | 5 V DC
Connector: 3-Pin A-RGB Plug + 3-Pin Socket
