ASUS ZenWiFi BD4 BE3600 Dual-band AI Mesh WiFi 7 Extendable Router (1 Pack)

Dual-band WiFi 7 (802.11be) AiMesh Extendable Router, 3.6 Gbps, Coverage up to 6500 sq. ft. (3pk), Dual 2.5G Ports, Up to 3 SSIDs for IoT Devices, Parental Controls & VPNs, Advanced Network Security

• Dual-band WiFi 7 speeds up to 3600 Mbps with MLO and 4K-QAM
• ASUS AiMesh technology boosts coverage up to 6500 sq. ft. (3-pack) and easy extendibility with compatible ASUS routers for seamless and secure whole home WiFi
• Four internal antennas and four high-power front-end modules eliminate WiFi dead zones
• 24/7 end-to-end protection with commercial-grade AiProtection Pro and advanced VPNs
• IoT Network, parental controls & VPN easy setup on multiple devices with Smart Home Master SSIDs
• Dual 2.5G Ethernet ports with auto detection
• Quad-core 1.5 GHz CPU and robust cooling

Model: ASUS ZenWiFi BD4
Model Name: BD4(B-1-PK)
Network Standard: IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 7 (802.11be) IPv4 IPv6
WiFi Data Rate: WiFi 7 (802.11be) (2.4GHz): up to 688 Mbps WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
Antenna: Internal antennas x 4
Transmit / Receive: 2.4GHz 2x2 5GHz 2x2
Processor: 1.5GHz quad-core processor
Memory: RAM 512MB , Flash 128MB
Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 4096-QAM high data rate 20/40/80/160 MHz bandwidth
Operating Frequency: 2.4 GHz 5 GHz
Operating Mode: Wireless Router Mode AiMesh Node Mode Access Point Mode
I/O Ports: 2.5G x 2 (WAN/LAN auto detecting)
Buttons: WPS button, Reset button, Power switch
LED Indicator: Power x 1
Power Supply: AC Input : 110V~240V(50~60Hz) DC Output : 12V with max 1.5A current
Package Content: ZenWiFi BD4 RJ45 cable Power adapter Warranty card Quick start guide
Product Dimensions: 140 x 70 x 140 mm

Remark: Content may vary in different regions and packages.
AiMesh: AiMesh • Primary AiMesh Router • AiMesh Node
Parental Control
"Allow you to block access to unwanted websites and apps." Web & Apps Filters Time Scheduling Reward Parental Control - Safe Browsing Customized Internet Schedule

Router APP
APP: ASUS Router APP

Guest Network
"The Guest Network provides Internet connection for guests but restricts access to your local network." Support Guest Network

Security
AiProtection VPN WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise WPS Let's Encrypt DNS-over-TLS Security Scan Firewall
AiProtection
AiProtection Pro • Router Security Assessment • Malicious Site Blocking • Two-Way IPS • Infected Device Prevention and Blocking

VPN
Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion

Traffic Control
Adaptive QoS • Bandwidth Monitor • Bandwidth Limiter Traditional QoS Traffic Monitor Traffic Analyzer • Website History

WAN
Port Forwarding Port Triggering DMZ DDNS

LAN
DHCP Server IGMP Snooping IPTV Manually Assign IP Address Wake on LAN (WOL)

Wireless
MU-MIMO UTF-8 SSID WiFi MAC Address Filter Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming

Administration
Diagnosis Tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update

Smart Home
Support Google Assistant
