The DM8 SE is a compact, high-efficiency cooling solution engineered for reliable thermal performance and quiet operation. Designed in a standard 120 × 120 × 28 mm form factor, it integrates seamlessly into a wide range of system builds while delivering strong airflow and consistent pressure for effective heat dissipation.
With a variable fan speed range of 800–1600 RPM (±10%), the DM8 SE balances cooling power and acoustic comfort, maintaining a maximum noise level of just 33.6 dBA. Its optimized blade design produces up to 58.0 CFM of airflow and 1.8 mm H₂O of static pressure, making it suitable for both case ventilation and heatsink applications.
Built with a durable hydro bearing, the DM8 SE ensures smooth, stable operation and an extended lifespan. Rated for up to 40,000 hours of mean time to failure (MTTF), it delivers long-term reliability for continuous use. Separate 5V power lines for the fan and LED provide efficient energy consumption, with low current draw to support modern system
Specification
Model: DM8 SE Normal Blade
Dimensions: 120 x 120 x 28 mm
Fan Speed: 800 - 1600 ± 10% RPM
Noise Level: 33.6 dBA (Max)
Airflow: 58.0 CFM
Static Pressure: 1.8 mm H2O
Current (Fan/LED): FAN ≤0.1 A / LED ≤0.25 A (5V)
Bearing Type: Hydro Bearing
MTTF: 40,000 hrs
