Model Specification
PERFORMANCE
Processor: AMD Ryzen™ 7 7735HS (8C / 16T, 3.2 / 4.75GHz, 4MB L2 / 16MB L3)
Graphics: NVIDIA GeForce RTX™ 4050 6GB GDDR6, Boost Clock 1605MHz, TGP 65W, 194 AI TOPS
Chipset: AMD SoC Platform
Memory: 1x 16GB SODIMM DDR5-4800
Memory Slots: Two DDR5 SODIMM slots, dual-channel capable
Max Memory : Up to 16GB DDR5-4800 offering
Storage: 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot: Two M.2 2242 PCIe® 4.0 x4 slots
Max Storage Support : Up to two drives, 2x M.2 SSD • M.2 SSD up to 1TB each
Optical: None
Card Reader: 3-in-1 Card Reader
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, optimized with Nahimic Audio
Microphone: 2x, Array
Camera: HD 720p with Privacy Shutter
Battery: 57.5Wh
Power Adapter: 135W Slim Tip (3-pin)
Special Features: AI Chip: LA1
DESIGN
Display: 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, FreeSync™
Touchscreen: None
Screen-to-Body Ratio: 88% AAR (active area ratio)
Color Calibration: No Color Calibration
Pen: Pen Not Supported
Keyboard: White Backlit, English
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 69 x 104 mm (2.72 x 4.09 inches)
Dimensions (WxDxH): 359.2 x 236 x 19.9-22.95 mm (14.14 x 9.29 x 0.78-0.90 inches)
Weight: Starting at 1.8 kg (3.97 lbs)
Case Color: Luna Grey
Case Material: PC-ABS (Top), PC-ABS (Bottom)
Surface Treatment: IMR (In-Mold Decoration by Roller)
SOFTWARE
Operating System: Windows® 11 Home Single Language, English
CONNECTIVITY
WLAN + Bluetooth: Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWANz: WWAN Not Supported
Ethernet: 100/1000M (RJ-45)
Standard Ports
2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-C® (USB 5Gbps), with USB PD 65-100W
1x HDMI® 2.1, up to 8K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x Card reader
1x Slim tip Power connector
SECURITY & PRIVACY
Security Chip: Firmware TPM 2.0 Enabled
Fingerprint Reader: No Fingerprint Reader
Other Security: Camera privacy shutter
MODEL INFORMATION
Model: 83S000BYPH
Machine Type: 83S0
