SPECIFICATION
Operating System: Windows 11 Home
Processor: Intel® Core™ i5-13450HX
Graphics: GeForce RTX™ 4050
Display: 15.6" Full-HD 144Hz
Memory: 8GB 4800MHz DDR5
Storage: 512GB M.2 PCIe NMVe SSD
Model: 83DV01F2PH
Machine Type: 83DV
AI PC Category: AI-Powered Gaming PC
Chipset: Intel® HM770 Chipset
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 Codec
Speakers: Stereo speakers, 2W ×2, Nahimic Audio optimized
Microphones: 2× Array microphones
Camera: HD 720p camera with Electronic Privacy Shutter (E-shutter)
Battery: 60Wh
Power Adapter: 170W Slim Tip (3-pin)
Special Features: Lenovo AI Chip: LA1
Screen-to-Body Ratio: 88% Active Area Ratio (AAR)
Color Calibration: None
Pen Support: Not supported
Keyboard: White Backlit Keyboard (English)
Touchpad: Buttonless Mylar® Precision TouchPad (PTP), Multi-touch, 75 × 120 mm
Dimensions (W × D × H): 359.86 × 258.7 × 21.9–23.9 mm (14.17 × 10.19 × 0.86–0.94 in)
Weight: Starting at 2.38 kg (5.25 lbs)
Case Color: Luna Grey (with White Backlit Keyboard)
Case Material: PC-ABS (Top), PC-ABS (Bottom)
Surface Finish: Painted finish
Wireless Connectivity: Wi-Fi® 6 (802.11ax) 2×2 + Bluetooth® 5.2
WWAN: Not supported
Ethernet: Gigabit Ethernet (RJ-45, 10/100/1000 Mbps)
USB Ports
3× USB-A (USB 5Gbps / USB 3.2 Gen 1)
1× USB-C® (USB 10Gbps / USB 3.2 Gen 2, USB Power Delivery 65–100W, DisplayPort™ 1.4)
Video Output
1× HDMI® 2.1 (up to 8K @ 60Hz)
Audio Jack
1× 3.5 mm Headphone / Microphone Combo Jack
Power Connector
1× Slim Tip Power Connector
Docking Support: Supports various USB-C® docking solutions (LOQ™ 15IRX9 compatible)
Security Chip: Firmware TPM 2.0 Enabled
Security Features
Electronic Camera Privacy Shutter (E-shutter)
Green Certifications
ErP Lot 3
RoHS Compliant
Military Standard
MIL-STD-810H Military Test Passed
Other Certifications
TÜV Rheinland® Low Blue Light (Software Solution)
