Specification
Model FA506NCQ-HN012W / 90NR0QE7-M001U0
Product Name: ASUS TUF Gaming A15
Operating System: Windows 11 Home
Color: Graphite Black
Processor: AMD Ryzen™ 7 170 Processor 3.2GHz (20MB Cache, up to 4.75 GHz, 8 cores, 16 Threads)
Chipset: TBD
Intergrated GPU: AMD Radeon™ Graphics
Discrete/Optimus: Optimus
Graphic: NVIDIA® GeForce RTX™ 3050 Laptop GPU
Graphic Wattage: Up to 1675MHz at 60W (75W with Dynamic Boost)
Graphic Memory: 4GB GDDR6
Panel Size: 15.6-inch
Resolution: FHD (1920 x 1080) 16:9
Refresh Rate: 144Hz
Viewing Angle: 85/85/85/85
Panel Tech: Value IPS-level
Brightness: 250nits
Contrast Ratio: 1000:1
NTSC %: 45%
SRGB %: 62.5%
Adobe %: 47.34%
DCI-P3 %: N/A
Surface texture of display: Anti-glare display
Adaptive-Sync technology: Adaptive-Sync
Pantone: N/A
Support Dolby Vision HDR: N/A
On board memory: N/A
DIMM Memory: 8GB DDR5-4800 SO-DIMM
Total System Memory: DDR5 8GB
Memory Slot: 2x SO-DIMM slots
Memory Max.: 64GB
Storage: 512GB PCIe® 4.0 NVMe™ M.2 SSD
M.2 slots support either SATA or NVMe: 2
M.2 SSD Support List
M.2 512GB G4x4 PCIe SSD
M.2 1TB G4x4 PCIe SSD
Expansion Slot (includes used)
- 2x DDR5 SO-DIMM slots
- 2x M.2 PCIe
LAN: 10/100/1000 Mbps
Wireless: Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.)
I/O Ports
- 1x RJ45 LAN port
- 1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ (data speed up to 10Gbps)
- 3x USB 3.2 Gen 1 Type-A (data speed up to 5Gbps)
Display output: 1x HDMI 2.1 TMDS
Camera: 720P HD camera
Mic: Built-in array microphone
Keyboard Type: Backlit Chiclet Keyboard 1-Zone RGB
Aura Sync: N/A
Touchpad: Touchpad
Speakers: 2-speaker system
Audio
- 1x 3.5mm Combo Audio Jack
- Built-in array microphone
Audio Tech
- AI noise-canceling technology
- DTS Audio Processing
- Hi-Res certification (for headphone)
Security
- BIOS Administrator Password and User Password Protection
- Kensington Security Slot™
- Trusted Platform Module (Firmware TPM)
Battery: 48WHrs, 3S1P, 3-cell Li-ion
Power: ø6.0, 180W AC Adapter, Output: 20V DC, 9A, 180W, Input: 100~240V AC, 50/60Hz universal
Dimension
Dimension (W x D x H): 35.9 x 25.6 x 2.28 ~ 2.45 cm (14.13" x 10.08" x 0.90" ~ 0.96")
Weight: 2.30 Kg (5.07 lbs)
